Data Sheet

Finish:

• Black Motor
• Bamboo blades

Blade Material:

• Plastic Alloy Composite - Suitable for outdoor and indoor use

Capability

• 3 Speed Wall Control Included - Remote control compatible please see related products
• Winter/Summer reversible airflow function

Light:

• 20w Built-in LED
• 2050lm max brightness
• CCT/Tri-colour: Warm/Cool/Daylight
• Step Dimmable with 4 steps

Airflow:

• 15,300 / 10,560 / 6,720m³/h

Power:

• 100 / 62 / 27W

Voltage:

• 240V

Dimensions:

• Overall Width: 1570mm
• Blade Height: 330mm
• Overall Height: 406mm

Remote:

• Remote controls are an added convenience for your AC fan and may make the installation process much easier. A remote control often removes the need for additional wiring if a lighting fixture already exists. If you are unsure if you require a remote or not feel free to contact us.

Extension Rod

• If your ceilings are raked steeper than 28 degrees, or are higher than average, an extension rod may be used to maximize the effects of your new ceiling fan.
• Extension Rods come in lengths of 900mm and can be cut to a suitable length by your electrician

Warranty:

• 6 year motor warranty
  • (2 year in home warranty, followed by a further 4 year motor warranty)
• All fans need to be installed by a licensed Electrician.
• If a fault becomes apparent please call the warranty number provided in the packaging of the ceiling fan, do not attempt to uninstall the ceiling fan.
• The Tax Invoice from the purchase of the fan, as well as the invoice from the licensed electrician will be required to claim warranty.
